Sandpiper® U1FB1XGTXNS600. U1F Top Discharge Metallic Ball Valve Pump

Part Number: U1FB1XGTXNS600.
The actual product may vary from images shown
$2,300.00
QTY:


U1FB1XGTXNS600. DETAILS

Sandpiper® U1FB1XGTXNS600. 1" NPT U1F Top Discharge Metallic Ball Valve Pump

UL pumps are designed to meet UL79 standards for diaphragm pumps handling flammable liquids. Fully groundable to prevent static discharge.

Recommended Accessories and Kits Sold Separately:

  • Sandpiper® 476.230.000 Air End Kit
  • Sandpiper® 476.213.635 Wet End Kit
  • Contact Us for Other Options and Accessories

U1FB1XGTXNS600. SPECS

  • Pump Type: U1F Metallic Design Level 1 Ball Valve Pump
  • Brand: SANDPIPER®
  • Wetted Material: Aluminum
  • Non-Wetted Material: Aluminum - No Paint
  • Main Material:
  • Air Inlet Size: 0
  • Check Valve Seat: Ball Valve
  • Check Valve Type: Ball
  • Diaphragm Material: Nitrile - Buna
  • Porting Position: NPT Threads
  • Air Inlet Connection Type:
  • Displacement per Stroke (gal): 0.11
  • Ball Material:
  • Elastomers: Nitrile - Buna
  • Inlet Size: 1
  • Inlet Connection Type: NPT
  • Max Air Inlet Pressure: 100
  • Max FLow Rate: 45 GPM
  • Max Solids Size: 0.25
  • Outlet Size: 1
  • Outlet Connection Type: NPT
  • Manifold Gasket:
  • Shipping Weight LBS: 27.00
  • Shipping Length IN: 12.50
  • Shipping Width IN: 10.25
  • Shipping Height IN: 12.72
  • Max Viscosity:
  • SKU: WRU1FB1XGTXNS600SP
  • MPN: U1FB1XGTXNS600.
  • Customs Code: HTS Code 8413.50.00.50
    Schedule B Code 8413.50.00.50
    HS Code 84131900
    ECCN Code EAR99
  • Seal Material:

TECHNICAL DOCUMENTS
