Sandpiper® SPE10BPPB0BP000UC1 1 In Center Ported Polypropylene EvolutionX™ AODD Pump w/ Nitrile - Buna Diaphragms; Replaces S1FB

Sandpiper® SPE10BPPB0BP000UC1 1 In Center Ported Polypropylene EvolutionX™ AODD Pump w/ Nitrile - Buna Diaphragms
Replacement Pump For Sandpiper S1FB3PBPPUS000.
Port Option: Center Ported
Air Distribution Valve: No-lube, no-stall design
Air Valve Option: Matched ground sleeve and spool
Exhaust Option: Encapsulated Polypropylene
Sandpiper Air End Kit 476.404.000
Sandpiper Wet End Kit 476.406.360

The SANDPIPER® EvolutionX™ 1" air operated double diaphragm pump design is the culmination of over 55 years of industry-leading research, development and engineering in pump & fluid dynamics. The EvolutionX represents the pinnacle of performance, efficiency and serviceability.

Enhanced Convenience
Exponentially reduce AODD pump assembly and service time:

• Reduced service time – EvolutionX takes, on average, five minutes to service the air distribution system compared to 45 minutes on average for other AODD pumps.
• Serviceability – All of the wet side nuts and bolts are the same size & length, and the use of washers has been eliminated. In fact, the EvolutionX has 50% fewer fasteners than the previous model.
• Accessibility – You can access air side components by removing only four bolts revealing an easily removable cartridge-style main air valve and pilot valve assembly.
• Improved stability for increased safety – We have added “stand-off feet” to the inner chambers to stabilize the pump on the workbench during disassembly.

Superior Performance & Efficiency
Improve overall efficiency and safety during operation while decreasing operating costs due to:

• Lower energy use – Achieves an incredible 20% average increase in air efficiency throughout the entire curve over our prior model.
• High flow – The EvolutionX has the highest flow rate of any other SANDPIPER® 1" AODD pump.

Increased Versatility
Meet countless configuration and application needs with interchangeable components, featuring:

• Durable, non-metallic construction rated for operation up to 125 psi with ATEX versions available.
• Numerous porting options:
• The standard EvolutionX configuration features a versatile 3-piece manifold with a universal ANSI & ISO flanged connection. Users can quickly adjust the discharge outlet for porting in multiple directions.
• Other porting options include a single-piece end-ported manifold or a dual-ported option to accommodate mixing or processing two fluids with a single pump.
• The mounting feet are extremely versatile and fit existing SANDPIPER® pumps and multiple other manufacturers’ dimensions.
