Sandpiper® F05B1SZSPTF000. 0.5" EP SS FDA-Compliant Metallic Ball Valve, PTFE 1 Piece Diaphragm

The Sandpiper® F05 ½" FDA-compliant pumps are EC 1935 certified for food-contacting materials. These ball valve pumps are ideally suited for a variety of food and beverage processing, pharmaceutical and cosmetic industry applications where electropolished surfaces are required.

As AODD pumps that are part of the Sandpiper® F-Series family of FDA pumps, they feature:

• Compliance with Food Contacting Materials requirements
  • 316 stainless steel wetted components electropolished to 125 u-in (3.175 u-m) finish
  • FDA Santoprene, PTFE, FDA Hytrel diaphragms, check balls and seats
• Bolted construction for more robust, leak-free performance than typical clamped-construction food pumps
• Maximum flow rate of 12 gpm (45 lpm)
• 1/2" tri-clamp connections
• Nickel-plated aluminum or polypropylene non-wetted components for compatibility with washdown chemicals

1/2" F-Series pumps are commonly used in:

• Clean-In-Place chemicals
• Chemical transfer and injection
• Ingredient and flavoring injection
• Fragrance injection
• Product transfer

Recommended Accessories and Kits Sold Separately:

• Sandpiper® 476.372.000 Air End Kit
• Sandpiper® 476.377.659 Wet End Kit
• Contact Us for Other Options and Accessories
