AMT® 5986-95B Submersible Drainage/Sump Utility Pump, 50 Hz Motor, BST Outlet

Part Number: 5986-95B
The actual product may vary from images shown
$691.50
QTY:


5986-95B DETAILS

AMT® 5986-95B Submersible Utility Pump, 3" BST Outlet (Drainage Type) with 50 Hz Motor.

AMT® Submersible Sump Pumps are designed for many applications including sump pits, drainage pits, overflow tanks, basements, dewatering, excavation, grain elevators, construction drainage, cooling towers and other applications requiring clear/drainage water removal. AMT® Submersible Pump include thermal overload protector and suction screen.

Features:

  • Cast iron construction
  • Built-in thermal protection
  • Tiplex seal system
    • Double mechanical seals: Carbon/Ceramic with Buna-N elastomers
    • Plus shaft seal
  • UL/CSA Listed.
  • 1 HP, 220 VAC @ 50 Hz UL/CSA Motor
  • 6 M Cord with 3 prong plug
  • Clog resistant impellers
  • Handles up to 7/32" Solids
  • Carry handle built-in
  • Stainless steel suction screen
  • Maximum temperature: 104 F

5986-95B FEATURES

  • Triplex Seal System: Double Mechanical Seals Plus Shaft Seal; Clog Resistant Impeller
  • Cast Iron Construction with Clog Resistant Impeller
  • Built-In Thermal Overload Protection
  • UL/CSA 6 Meter Cord with 3 Prong Plug
  • 1 HP, 220 VAC/50 Hz, 7 Full Load Amps Motor
  • Stainless Steel Strainer
  • Inlcudes Hose Adapter for Outlet
  • Handles 7/32" Max Solids Size

5986-95B SPECS

  • Pump Type: Submersible Drainage
  • Brand: AMT®
  • Shipping Weight LBS: 53
  • Shipping Length IN: 7.5
  • Main Material: Cast Iron
  • Displacement per Stroke (gal):
  • Shipping Height IN: 18.8
  • SKU: AT598695BSP
  • Engine Type:
  • MPN: 5986-95B
  • Full Load Current: 7
  • Customs Code: HTS Code 8413702004
    Schedule B Code 8413702004
    ECCN Code EAR99
  • Fuel Tank Capacity:
  • Driver Type: Electric Motor
  • Shipping Width IN: 11.8
  • Outlet Size: 3
  • Model #:
  • Inlet Size:
  • Motor Frame:
  • Elastomers: Buna-N
  • Outlet Connection Type: FBST
  • Porting Position:
  • Inlet Connection Type:
  • Max Solids Size: 0.219
  • Run Time:
  • RPM: 2850
  • Max FLow Rate: 170 GPM
  • Power: 1
  • Seal Material: Carbon/Ceramic Double Mechanical Plus Shaft Seal, Buna -N Elastomers
  • Max Discharge Pressure: 15.1
