AMT® 3P9XLR 3" 8 HP Engine Driven Self-Priming Portable High Pressure Pumps

Part Number: 3P9XLR
The actual product may vary from images shown
$1,653.00
QTY:


3P9XLR DETAILS

AMT® 3P9XLR 3" 8 HP Engine Driven Self-Priming Portable High Pressure Pumps

IPT Portable High Volume, Self-priming Centrifugal Trash pumps come standard with a cast iron impeller to resist abrasion and one tool serviceability for easy cleanout. All pumps feature aluminum housing, cast iron wearparts, built-in check valve, suction strainer and heavy duty steel roll frame. Heavy duty cast iron flanges with male NPT threads that rotates in 90° increments. Easy access fill plug on discharge port.

3P9XLR FEATURES

  • Cast Aluminum Construction with Cast Iron Diffusers
  • EPDM/EPR Mechanical Seals
  • Optional FKM Seal and Elastomers Available
  • 3" Cast Iron Suction & Discharge Male NPT Port Sizes
  • Maximum Flow up to 185 GPM
  • Maximum Head up to 89 PSI
  • Maximum Lift to 26 Ft.
  • One Tool Serviceability
  • Utilized for Fire Protection or Irrigation
  • Discharge Port Rotates in 90° Increments
  • Engine Options

3P9XLR SPECS

  • Pump Type: Self-Priming High Pressure Centrifugal
  • Brand: AMT®
  • Shipping Weight LBS: 145
  • Shipping Length IN: 31
  • Main Material: Aluminum Diecast
  • Displacement per Stroke (gal):
  • Shipping Height IN: 23.6
  • SKU: AT3P9XLRSP
  • Engine Type: LCT® 306CC
  • MPN: 3P9XLR
  • Full Load Current:
  • Fuel Tank Capacity: 0.95/3.6, not qt
  • Customs Code:
  • Shipping Width IN: 22.5
  • Driver Type:
  • Outlet Size: 3
  • Inlet Size: 3
  • Elastomers: EPDM
  • Motor Frame:
  • Outlet Connection Type: NPT
  • Model #:
  • Inlet Connection Type: NPT
  • Max Solids Size:
  • Porting Position:
  • Max FLow Rate: 180 GPM
  • Power: 8
  • Run Time: 132.00 min
  • RPM:
  • Seal Material:
  • Max Discharge Pressure:
