AMT® 3931-99 Self-Priming Solids Handling Centrifugal Pump with Bearing Pedestal

AMT® 3931-99 Self-Priming Solids Handling Pedestal Pump, 5 HP Minimum Required at 3600 RPM.

AMT® Self-Priming Solids Handling Pedestal Pumps are designed for direct or belt drive with either an electric motor or a gas/diesel engine. This unit features 1" solids handling construction and is fitted with a cast iron bearing housing, which contains two precision sealed ball bearings. Easy clean-out design by removing casing bolts permits removal of debris without disconnecting hoses.

Features:

• Cast iron construction
• Silicon Carbide/Silicon Carbide seal with Viton® elastomers
• Viton® check valve and o-rings
• Self-primes to 20 Ft. with built-in check valve
• 2" NPT suction & discharge ports
• 1" Diameter solids handling capability
• Heavy duty cast iron bearing housing containing (2) precision sealed ball bearings
• 3/4" Diameter CNC Machined Shaft with 1-3/8" x 3/16" x 3/32" Keyway.

This unit does NOT come with a motor/engine

Links to repair kits and optional equipment (where available) are located at the top and bottom of this page for your convenience.
* AMT® 3931-99
