AMT® 3160-99 Self-Priming Solids Handling Centrifugal Pump with Bearing Pedestal

AMT® 3160-99 Self-Priming Solids Handling Pedestal Pump, 3 HP Minimum Required at 3600 RPM.

AMT® Self-Priming Solids Handling Pedestal Pumps are designed for direct or belt drive with either an electric motor or a gas/diesel engine. Cast iron construction material. This unit features 3/8" solids handling construction and is fitted with a cast iron bearing housing, which contains two precision sealed ball bearings. Easy clean-out design by removing casing bolts permits removal of debris without disconnecting hoses.

Features:

• Cast iron construction
• Carbon/Ceramic seal with Buna-N check valve and o-rings
• Self-primes to 20 Ft. with built-in check valve
• Optional SiC/SiC seal with Viton® elastomers available
• Self-priming to 20 Ft. with built-in check valve
• Maximum working pressure: 75 PSI
• Maximum temperature: 180 F (200 F w/optional Viton® seal)
• Solids handling capability size: 3/8"
• 3/4" Diameter CNC Machined Shaft with 1 3/8" x 3/16" x 3/32" Keyway

This unit does NOT come with a motor/engine

Links to repair kits and optional equipment (where available) are located at the top and bottom of this page for your convenience.
* AMT® 3160-99
