AMT® 2S5XLR 2" 5 HP Engine Driven Self-Priming High Trash Pump

Part Number: 2S5XLR
The actual product may vary from images shown
$1,078.00
QTY:


2S5XLR DETAILS

AMT® 2S5XLR 2" 5 HP Engine Driven Self-Priming High Trash Pump

IPT Portable High Volume, Self-priming Centrifugal Trash pumps come standard with a cast iron impeller to resist abrasion and one tool serviceability for easy cleanout. All pumps feature aluminum housing, cast iron wearparts, built-in check valve, suction strainer and heavy duty steel roll frame. Heavy duty cast iron flanges with male NPT threads that rotates in 90° increments. Easy access fill plug on discharge port.

2S5XLR FEATURES

  • Cast Aluminum Construction with Cast Iron Diffusers
  • EPDM/EPR Mechanical Seals
  • Optional FKM Seal and Elastomers Available
  • 3" Cast Iron Suction & Discharge Male NPT Port Sizes
  • Maximum Flow up to 185 GPM
  • Maximum Head up to 89 PSI
  • Maximum Lift to 26 Ft.
  • One Tool Serviceability
  • Utilized for Fire Protection or Irrigation
  • Discharge Port Rotates in 90° Increments
  • Engine Options

2S5XLR SPECS

  • Pump Type: Self-Priming High Pressure Centrifugal
  • Brand: AMT®
  • Shipping Weight LBS: 90
  • Shipping Length IN: 24
  • Main Material: Aluminum Diecast
  • Displacement per Stroke (gal):
  • Shipping Height IN: 19.9
  • SKU: AT2S5XLRSP
  • Engine Type: LCT® 208CC
  • MPN: 2S5XLR
  • Full Load Current:
  • Fuel Tank Capacity: 0.71/2.7, not qt
  • Customs Code:
  • Shipping Width IN: 19.5
  • Driver Type:
  • Outlet Size: 2
  • Inlet Size: 2
  • Elastomers: FKM
  • Motor Frame:
  • Outlet Connection Type: NPT
  • Model #:
  • Inlet Connection Type: NPT
  • Max Solids Size: 1.25
  • Porting Position:
  • Max FLow Rate:
  • Power: 5
  • Run Time: 132.00 min
  • RPM:
  • Seal Material:
  • Max Discharge Pressure:
