Home / AMT® Pumps / 2S5X 2" Self-Priming Trash Centrifugal Pump Kit, 5/8" Threaded Shaft

2S5X 2" Self-Priming Trash Centrifugal Pump Kit, 5/8" Threaded Shaft

Part Number: 2S5X
The actual product may vary from images shown
$519.75
QTY:


2S5X DETAILS

IPT® 2S5X Self-Priming Trash Pump

5/8" THREADED PUMP KIT ONLY. DOES NOT INCLUDE MOTOR OR ROLL CAGE.

IPT® portable high volume, self-priming centrifugal trash pumps come standard with a cast iron impeller to resist abrasion and one tool serviceability for easy clean-out. Silicon Carbide mechanical seal with graphite impregnated seat and Viton® Elastomers. Removable, heavy duty cast iron flanges with male NPT threads that rotate in 90 degree increments. Handles up to 1 1/4" solids.

Features:

  • Self-Primes to 26 ft with built in check valve
  • Handles up to 1 1/4" Solids
  • SiC/Car Seal w/ Viton® Elastomers
  • EPDM/EPR O-Rings
  • Aluminum housing
  • Cast iron impeller and wear parts
  • Built-in check valve
  • Suction strainer
  • Easy access fill plug on discharge port
  • One Tool Serviceability- Tool Included
  • Vibration Dampening Feet

Optional Equipment:

Viton® O-Ring and Check Valve Installed at Factory (Seal not included- pump already equiped with SiC/Car Seal
Wheel Kit
See Optional Equipment Links at the Top and Bottom of the Page!
* IPT® 2S5X

2S5X FEATURES
  • Cast Aluminum Construction with Cast Iron Wear Parts
  • SiC/SiC Viton® Mechanical Seal with EPDM/EPR O-Rings
  • Self-Priming to 26 Ft. with Built in EPDM/EPR Check Valve
  • Removable Male NPT Suction & Discharge Ports Rotate in 90 Degree Increments
  • Easy Clean Out with One Tool Serviceability
  • Maximum Solids Size: 1"
  • Heavy Duty Steel Roll Frame Included
  • Optional Viton® O-Ring / Check Valve and 10" Semi-Pneumatic Wheel Kit Available (C402-90)

2S5X SPECS

  • Pump Type: Self-Priming Trash Centrifugal
  • Brand: IPT®
  • Shipping Weight LBS: 40
  • Shipping Length IN: 18
  • Main Material: Aluminum
  • Displacement per Stroke (gal):
  • Shipping Height IN: 16
  • SKU: AT2S5XSP
  • Engine Type:
  • MPN: 2S5X
  • Full Load Current:
  • Fuel Tank Capacity:
  • Customs Code: HTS Code 8413702015
    Schedule B Code 8413702015
    ECCN Code EAR99
  • Shipping Width IN: 15
  • Driver Type: Bearing Pedestal
  • Outlet Size: 2
  • Inlet Size: 2
  • Elastomers: EPDM/EPR
  • Motor Frame:
  • Outlet Connection Type: MNPT
  • Model #:
  • Inlet Connection Type: MNPT
  • Max Solids Size:
  • Porting Position:
  • Max FLow Rate: 240 GPM
  • Power: 5
  • Run Time:
  • RPM: 3450
  • Seal Material: Carbon/Ceramic Mechanical Seal, EPDM/EPR Elastomers
  • Max Discharge Pressure: 54.5
