AMT® 2761-95 Self-Priming Centrifugal Pump

Part Number: 2761-95
The actual product may vary from images shown
$825.75
QTY:


2761-95 DETAILS

AMT® 2761-95 Self-Priming Centrifugal Pump.

This line of AMT® self-priming centrifugal pumps is designed for industrial and commercial applications requiring high volume liquid transfer, waste water drainage and processing. This pump featuresa self-cleaning, clog resistant impeller capable of handling up to 3/8" diameter semi-solids. Built-in flapper/check valve enables consistent self-priming to 20 Ft. Dual volute design reduces radial load on motor.

Features:

  • Cast iron construction
  • Self-cleaning, clog resistant impeller
  • Carbon/Ceramic seal with Buna-N elastomers
  • SiC/SiC seal with Viton® elastomers and check valve available
  • NEMA 56J motor with stainless steel shaft
  • Dual volute design
  • Self-priming to 20 Ft. with built-in check valve
  • Maximum working pressure: 75 PSI
  • Includes
    • Steel base
    • Carrying handle
Hazardous Duty/Xplosion Proof motors available from stock ranging from 1 to 10 HP.

Interchangeable with Grainger Part # 1P897; Dayton Part # 4UA76; Teel Part # 4UA76


* AMT® 2761-95

2761-95 FEATURES
  • Cast Iron Construction with Self-Cleaning, Clog Resistant Impeller
  • Carbon/Ceramic Buna-N Mechanical Seal
  • Optional SiC/SiC Viton® Mechanical Seal Installed by Factory (276X-301-VS) or SiC/SiC Viton® Mechanical Seal and Check Valve (276X-300-VS)
  • Consistent Self-Priming to 20 Ft with Built-In Check Valve with Built-In Buna-N Flapper/Check Valve
  • 2 HP ODP (Open Drip Proof), Single Phase, 56J Frame Motor

2761-95 SPECS

  • Pump Type: Self-Priming Centrifugal
  • Brand: AMT®
  • Shipping Weight LBS: 73
  • Shipping Length IN: 19.3
  • Main Material: Cast Iron
  • Displacement per Stroke (gal):
  • Shipping Height IN: 11.1
  • SKU: AT276195SP
  • Engine Type:
  • MPN: 2761-95
  • Full Load Current:
  • Fuel Tank Capacity:
  • Customs Code: HTS Code 8413702015
    Schedule B Code 8413702015
    ECCN Code EAR99
  • Shipping Width IN: 7.5
  • Driver Type: Electric Motor
  • Outlet Size: 2
  • Inlet Size: 2
  • Elastomers: Buna-N
  • Motor Frame: 56J
  • Outlet Connection Type: FNPT
  • Model #:
  • Inlet Connection Type: FNPT
  • Max Solids Size: 0.375
  • Porting Position:
  • Max FLow Rate: 127 GPM
  • Power: 2
  • Run Time:
  • RPM: 3450
  • Seal Material: Carbon/Ceramic Mechanical Seal, Buna -N Elastomers
  • Max Discharge Pressure: 36.7999999999999
