AMT 4S14KLR 4" Cast Aluminum Trash Pump, Kohler CH440 Engine

Part Number: 4S14KLR
The actual product may vary from images shown
$3,236.25
QTY:


4S14KLR DETAILS

AMT 4S14KLR 4" Cast Aluminum Trash Pump, Kohler CH440 Engine

AMT Portable High Volume, Self-priming Centrifugal Trash pumps include easy cleanout with replaceable cast iron impeller and volute that resist abrasion/wear. Pumps are designed to handle liquids with solids content or dissolved solids and debris. All pumps feature aluminum housing, cast iron wearparts, built-in check valve, suction strainer and heavy duty steel roll frame. Heavy duty cast iron flanges with male NPT threads that rotates in 90° increments. Easy access fill plug on discharge port.

Discharge Size / Connection: 4" NPT
Suction Size / Connection: 4" NPT
Main Construction Materials: Cast Aluminum
Solids Handling (In): 1.5
Seal: Viton/Silicon Carbide
Horsepower: 13
FrameYes
Engine Type: Kohler CH440
Tank Size (Gal/Ltr): 1.95/7.0
Run Time (Hr): 3.5

4S14KLR FEATURES
  • Cast Aluminum with Internal Cast Iron Wearparts for Durability
  • Silicon Carbide/Viton® Mechanical Seal
  • EPDM/EPR O-Rings Standard with Optional Viton®
  • 3" or 4" Removable Male NPT Suction and Discharge Ports
  • Discharge Rotates in 90° Increments
  • Engine Options: Honda or LCT Storm Force Gasoline or Hatz Diesel Engines
  • Solids Handling and Dirty Water Design
  • Maximum Solids Handling up to 2"
  • Maximum Flow up to 530 GPM
  • Maximum Head up to 112 Ft.
  • Self-Priming to 26 Ft.
  • Wheel Kit Optional

4S14KLR SPECS

  • Pump Type:
  • Brand: AMT®
  • Shipping Weight LBS: 240.00
  • Shipping Length IN: 31.00
  • Main Material: Cast Aluminum
  • Displacement per Stroke (gal):
  • Shipping Height IN: 23.60
  • Engine Type: Kohler CH440
  • SKU: AT4S14KLRSP
  • MPN: 4S14KLR
  • Full Load Current:
  • Fuel Tank Capacity: 7.80 qt
  • Customs Code:
  • Driver Type:
  • Shipping Width IN: 22.50
  • Outlet Size: 4
  • Inlet Size: 4
  • Elastomers:
  • Model #:
  • Motor Frame: Yes
  • Outlet Connection Type: NPT
  • Porting Position:
  • Inlet Connection Type: NPT
  • Max Solids Size: 1.5
  • Run Time: 210.00 min
  • Max FLow Rate:
  • Power: 13
  • RPM:
  • Seal Material:
  • Max Discharge Pressure:
