AMT 388F-98 1 1/2" NPT 1/2 HP Stainless Steel Inline Centrifugal

Part Number: 388F-98
The actual product may vary from images shown
$681.00
QTY:


388F-98 DETAILS

AMT 388F-98 1 1/2" NPT 1/2 HP Stainless Steel Inline Centrifugal

AMT Bronze & Stainless Steel Inline Centrifugal pumps are designed for use with most gravity fed service applications requiring liquid transfer. All models are fitted with a self-cleaning stainless steel impeller for maximum 1/8″ diameter solids handling. Units feature pull-from-rear design for easy servicing without removing piping. Pumps are not self-priming and require flooded suction.

Discharge Size / Connection: 1.5" FNPT
Suction Size / Connection: 1.5" FNPT
Main Construction Materials: Stainless Steel
Solids Handling (In): 0.125
Shaft Seal Materials: Buna-N/SS
Horsepower: 0.5Type: TEFC
Frame56J
Phase: 1
VAC/60 Hz: 115/208-230
Full Load Amps: 8/4

388F-98 FEATURES
  • Bronze or Stainless Steel Construction
  • Buna-N Mechanical Seal and O-Ring
  • Maximum Working Pressure 75 PSI
  • Maximum Temperature 180° F
  • Maximum Flow 130 GPM
  • Maximum Head 62 Ft.
  • Self-Cleaning, 1/8" Diameter Solids Handling Stainless Steel Impeller
  • 1/2 to 2 HP Totally Enclosed Fan Cooled (TEFC) Single Phase Motor

388F-98 SPECS

  • Pump Type:
  • Brand: AMT®
  • Shipping Weight LBS: 41.00
  • Shipping Length IN: 13.00
  • Main Material: Stainless Steel
  • Displacement per Stroke (gal):
  • Shipping Height IN: 8.70
  • SKU: AT388F98SP
  • Engine Type:
  • MPN: 388F-98
  • Full Load Current: 8/4
  • Fuel Tank Capacity:
  • Customs Code:
  • Shipping Width IN: 8.90
  • Driver Type:
  • Outlet Size: 1.5
  • Inlet Size: 1.5
  • Elastomers:
  • Motor Frame: 56J
  • Outlet Connection Type: FNPT
  • Model #:
  • Inlet Connection Type: FNPT
  • Max Solids Size: 0.125
  • Porting Position:
  • Max FLow Rate:
  • Power: 0.5
  • Run Time:
  • RPM:
  • Seal Material:
  • Max Discharge Pressure:
