Nomad® 80-211968 3 TRANS-FLO™ GOLD AODD Pump, Ductile Iron Polyurethane Diaphragms & BSP Ports (ATEX)

Part Number: 80-211968
The actual product may vary from images shown
$3,085.35
QTY:


80-211968 DETAILS

Nomad® 80-211968 3 TRANS-FLO™ GOLD AODD Pump, Ductile Iron Polyurethane Diaphragms & BSP Ports (ATEX)

MODEL # NTG80/WAAN/PU/PU/PU/B/C/X


Nomad®™ low cost, high quality TRANS-FLO™ GOLD™ air operated double diaphragm pumps.
Similar and Comparable to Wilden® M and T Series

TRANS-FLO™ GOLD™ pumps feature a simple, time proven design. Simple to maintain with readily available parts. Fast assembly and delivery time. The TRANS-FLO™ GOLD™ Air-Distribution System is a non-stalling design for consistent performance. Nomad®™ AODD pumps also feature Tracker™ Seals: Nomad®™ shaft o-ring seals feature a proprietary design created by the world's preeminent seal material specialist. Low cost, water resistant & easy to install, the Tracker™ Seal allows for a sharp shift & quality on/off reliability.
Model Code NTG80/WAAN/PU/PU/PU/B/C/X

80-211968 FEATURES
  • Drop in replacement for Wilden® AODD pumps of equivalent make and size
  • Featuring TRANS FLO GOLD Air Distribution System; a simple, non-stalling design
  • TRANS FLO GOLD features a patent pending differential cap design
  • Tracker™ shaft seals allow for sharp shifts and quality on/off reliability
  • Time proven design that is simple to maintain
  • Air driven double diaphragm pumps handle large solids and slurries

80-211968 SPECS

  • Pump Type: TRANS-FLO GOLD NTG80
  • Brand: NOMAD®
  • Wetted Parts: Ductile Iron
  • Non-Wetted Material: Aluminum
  • Air Inlet Size: 0.75
  • Air Consumption:
  • Max Air Inlet Pressure: 125
  • Air Valve Material: Brass
  • Air Inlet Connection Type:
  • Ball Material: polyurethane
  • Center Block Material: Aluminum
  • Connection Style: Clamped
  • ATEX: ATEX
  • Diaphragm Material: polyurethane
  • Displacement per Stroke (gal): 1.40
  • Elastomers: Polyurethane, Polyurethane
  • Fittings: Clamped
  • Inlet Size: 3
  • Discharge Pressure:
  • Inlet Connection Type: BSP
  • Max Flow Rate (GPM): 232
  • Max Delivered Pressure: 0
  • Max Solids Size: 0.375
  • Model #: NTG80/WAAN/PU/PU/PU/B/C/X
  • Outlet Size: 3
  • Main Material: Ductile
  • Outlet Connection Type: BSP
  • Porting Position: Center Ported
  • Max Discharge Pressure:
  • Valve Balls Material: polyurethane
  • Valve Seat Material: polyurethane
  • Valve Seat O-Ring:
  • Shipping Weight LBS: 200.00
  • Shipping Length IN: 17.00
  • Shipping Width IN: 11.00
  • Shipping Height IN: 31.90
  • SKU: NM80211968SP
  • Seal Material:
  • MPN: 80-211968
  • Customs Code: HTS Code 8413.50.00.50
    Schedule B Code 8413.50.00.50
