Nomad® 80-21161 3 PWR-FLO™ AODD Pump, Ductile Iron PTFE(w/ Neo back-up) Diaphragms & BSP Ports

Part Number: 80-21161
The actual product may vary from images shown
$5,199.02
QTY:


80-21161 DETAILS

Nomad® 80-21161 3 PWR-FLO™ AODD Pump, Ductile Iron PTFE(w/ Neo back-up) Diaphragms & BSP Ports
The Nomad®™ low cost, high quality PWR-FLO™ air operated double diaphram pumps.
Similar and Comparable to Wilden® Standard P Series "Pro-Flo® Valve Design"

PWR-FLO™™ asymmetrical spool design (ASD) features an efficient air system. The anti-stalling design also provides excellent reliability in on/off liquid transfer for filling and batching applications.
Model: NPF80/WAAP/TF/TF/MTF/B/C

  • 3" Model
  • Connection: BSP
  • Wet End Material: Ductile
  • Air Chamber: Aluminum

Model Code NPF80/WAAP/TF/TF/MTF/B/C

80-21161 FEATURES
  • Drop in replacement for Wilden® AODD pumps of equivalent make and size
  • Air driven double diaphragm pumps handle large solids and slurries
  • PWR-FLO™ asymmetrical spool design (ASD) features an efficient air system
  • The anti-stalling design also provides excellent reliability in on/off liquid transfer for filling and batching applications

80-21161 SPECS

  • Pump Type: PWR-FLO NPF80
  • Brand: NOMAD®
  • Wetted Parts: Ductile Iron
  • Non-Wetted Material: Aluminum
  • Air Inlet Size: 0.75
  • Air Consumption:
  • Max Air Inlet Pressure: 125
  • Air Valve Material: Polypropylene
  • Air Inlet Connection Type:
  • Ball Material: PTFE
  • Center Block Material: Aluminum
  • Connection Style: Clamped
  • ATEX:
  • Diaphragm Material: PTFE(with Neoprene back-up)
  • Displacement per Stroke (gal): 1.49
  • Elastomers: PTFE, PTFE, PTFE
  • Fittings: Clamped
  • Inlet Size: 3
  • Discharge Pressure:
  • Inlet Connection Type: BSP
  • Max Flow Rate (GPM): 232
  • Max Delivered Pressure: 0
  • Max Solids Size: 0.375
  • Model #: NPF80/WAAP/TF/TF/MTF/B/C
  • Outlet Size: 3
  • Main Material: Ductile
  • Outlet Connection Type: BSP
  • Porting Position: Center Ported
  • Valve Balls Material: PTFE
  • Max Discharge Pressure:
  • Valve Seat Material:
  • Valve Seat O-Ring: PTFE
  • Shipping Weight LBS: 205.00
  • Shipping Length IN: 19.90
  • Shipping Width IN: 16.00
  • Shipping Height IN: 32.40
  • SKU: NM8021161SP
  • Seal Material:
  • MPN: 80-21161
  • Customs Code: HTS Code 8413.50.00.50
    Schedule B Code 8413.50.00.50
