NOMAD® 50-22664-1 2" NPT PWR-FLO™ AODD Pump, Polypropylene w/ Hytrel® Diaphragms, Clamped

Part Number: 50-22664-1
The actual product may vary from images shown
$4,255.62
QTY:


50-22664-1 DETAILS

NOMAD® 50-22664-1 2" Clamped NPT PWR-FLO™ AODD Pump, Polypropylene w/ Hytrel® Diaphragms

The PWR-FLO™ asymmetrical spool design (ASD) features the most efficient air system available. The anti-stalling design also provides excellent reliability in on/off liquid transfer for filling and batching applications. The air valve and center section is made of chemically resistant polypropylene. NOMAD® pumps are self-priming, can handle viscous and abrasive products and can run dry without damage.

50-22664-1 FEATURES
  • Drop in replacement for Wilden® AODD pumps of equivalent make and size
  • Air driven double diaphragm pumps handle large solids and slurries
  • PWR-FLO™ asymmetrical spool design (ASD) features an efficient air system
  • The anti-stalling design also provides excellent reliability in on/off liquid transfer for filling and batching applications
  • The air valve and center section is made of chemically resistant polypropylene.

50-22664-1 SPECS

  • Pump Type: PWR-FLO NPF50
  • Brand: NOMAD®
  • Wetted Parts: Polypropylene
  • Non-Wetted Material:
  • Air Inlet Size: 0.5
  • Air Consumption:
  • Max Air Inlet Pressure: 125
  • Air Valve Material: Polypropylene
  • Air Inlet Connection Type: NPT
  • Ball Material:
  • Center Block Material: Polypropylene
  • Connection Style:
  • ATEX:
  • Diaphragm Material: Hytrel®
  • Displacement per Stroke (gal): 0.69
  • Elastomers: Viton, PTFE (with Neoprene back-up)
  • Fittings:
  • Inlet Size: 2
  • Discharge Pressure:
  • Inlet Connection Type: NPT
  • Max Flow Rate (GPM): 148
  • Max Delivered Pressure: 0
  • Max Solids Size: 0.25
  • Model #:
  • Outlet Size: 2
  • Main Material: Polypropylene
  • Outlet Connection Type: NPT
  • Porting Position: Center Ported
  • Max Discharge Pressure:
  • Valve Balls Material: PTFE (with Neoprene back-up)
  • Valve Seat Material: Polypropylene
  • Valve Seat O-Ring: Viton
  • Shipping Weight LBS: 75.00
  • Shipping Length IN: 30.30
  • Shipping Width IN: 13.10
  • Shipping Height IN: 30.30
  • SKU: NM50226641SP
  • Seal Material:
  • MPN: 50-22664-1
  • Customs Code: HTS Code 8413.50.00.50
    Schedule B Code 8413.50.00.50
