Home / Nomad / NOMAD® Pumps / NOMAD® 25-68966 1" TRANS-FLO™ AODD Pump, 316SS with Garlock® PTFE/EPDM Diaphragms & FNPT Ports

NOMAD® 25-68966 1" TRANS-FLO™ AODD Pump, 316SS with Garlock® PTFE/EPDM Diaphragms & FNPT Ports

Part Number: 25-68966
The actual product may vary from images shown
$4,299.97
QTY:


25-68966 DETAILS

NOMAD® 25-68966 1" TRANS-FLO™ GOLD AODD Pump, 316SS with Garlock®® PTFE/EPDM Diaphragms & FNPT Ports
316 S.S. MODEL
1” MODEL
NTG25/SAAB/TGE/TF/STF/N/X
NOMAD®™ low cost, high quality TRANS-FLO™ GOLD™ air operated double diaphragm pumps.
Similar and Comparable to Wilden® M and T Series

TRANS-FLO™ GOLD™ pumps feature a simple, time proven design. Simple to maintain with readily available parts. Fast assembly and delivery time. The TRANS-FLO™ GOLD™ Air-Distribution System is a non-stalling design for consistent performance. NOMAD®™ AODD pumps also feature Tracker™ Seals: NOMAD®™ shaft o-ring seals feature a proprietary design created by the world's preeminent seal material specialist. Low cost, water resistant & easy to install, the Tracker™ Seal allows for a sharp shift & quality on/off reliability.

  • Wet End Material: 316SS
  • Air Chambers: Aluminum
  • Center Block: Aluminum
  • Air Valve: Brass
  • Connection Type: FNPT

Model Code NTG25/SAAB/TGE/TF/STF/N/B/X

25-68966 FEATURES
  • Drop in replacement for Wilden® AODD pumps of equivalent make and size
  • Featuring TRANS FLO GOLD Air Distribution System; a simple, non-stalling design
  • TRANS FLO GOLD features a patent pending differential cap design
  • Tracker™ shaft seals allow for sharp shifts and quality on/off reliability
  • Time proven design that is simple to maintain
  • Air driven double diaphragm pumps handle large solids and slurries

25-68966 SPECS

  • Pump Type: TRANS-FLO GOLD NTG25
  • Brand: NOMAD®
  • Wetted Parts: 316SS
  • Non-Wetted Material:
  • Air Inlet Size: 0.25
  • Air Consumption:
  • Max Air Inlet Pressure: 125
  • Air Valve Material: Brass
  • Air Inlet Connection Type:
  • Ball Material: PTFE/Neoprene
  • Center Block Material: Aluminum
  • Connection Style: Bolted
  • ATEX:
  • Diaphragm Material: Garlock® PTFE/EPDM
  • Displacement per Stroke (gal): 0.05
  • Elastomers: PTFE, PTFE/Neoprene, PTFE/Neoprene
  • Fittings: Bolted
  • Inlet Size: 1
  • Discharge Pressure: 120
  • Inlet Connection Type: NPT
  • Max Flow Rate (GPM): 25
  • Max Delivered Pressure: 120
  • Max Solids Size: 0.125
  • Model #: NTG25/SAAB/TGE/TF/STF/N/B/X
  • Outlet Size: 0.75
  • Main Material: 316SS
  • Outlet Connection Type: NPT
  • Porting Position: Center Ported
  • Valve Balls Material: PTFE/Neoprene
  • Max Discharge Pressure: 120
  • Valve Seat Material: Stainless Steel
  • Valve Seat O-Ring: PTFE
  • Shipping Weight LBS: 25.00
  • Shipping Length IN: 7.30
  • Shipping Width IN: 10.50
  • Shipping Height IN: 11.00
  • SKU: NM2568966SP
  • Seal Material:
  • MPN: 25-68966
  • Customs Code: HTS Code 8413.50.00.50
    Schedule B Code 8413.50.00.50
